Product Description
This hard drive will allow you to add a 2nd hard drive to your Dell Notebook
Computers by using the optical drive bay. Simply remove your optical drive and
put this hard drive in it's place, you will have an extra hard drive for your
Dell notebook computer. This is an excellent solution for adding extra storage
or back up data from primary hard drive. Hard Drive Features:
Capacity: 120GB~320GB at your selection
Rotational Speed: 5,400 rpm or 7200 rpm at your selection
Cache: 8 MB
Seek Time:
Track to track: 1.5 ms
Average: 12 ms
Front View
This hard
drive is compatible with following Dell notebook computers:
DELL Latitude : D400, D500, D505, D510,D600 D610 D620 D800 D810, X300 &
more...
DELL Inspiron : 8500, 8600, 9100, 300M, 500M, 510M, 600M, XPS & more...
DELL Precision : M20, M60, M70,M90 & more...
For more compatible
models, please use our our Dell
Laptop/Notebook Upgrade Guide. If this drive is directly (which means
you can see "Order" button ) listed under your notebook model page, it means it
should fit your notebook computer.
How to remove optical drive?
In order to install this 2nd hard drive to your Dell notebook computers, you
need to remove the optical drive and install the 2nd hard drive into the optical
drive bay. Here is how to remove the optical drive:
If the Device
Security Screw Is Not Installed
NOTICE: To prevent damage to
devices, place them in a safe, dry place when they are not installed in the
computer. Avoid pressing down on them or placing heavy objects on top of
them.
1. Press the device latch release so that the latch release pops
out.
2.
Pull the device by the latch release to remove the device from the module
bay.
If the Device
Security Screw Is Installed
1. If the computer is connected to a
docking device (docked), undock it. See the documentation that came with your
docking device for instructions.
NOTICE: To prevent damage to devices,
place them in a safe, dry place when they are not installed in the computer.
Avoid pressing down on them or placing heavy objects on top of them.
2.
Close the display and turn the computer over.
3. Use a #1 Phillips
screwdriver to remove the M2 x 3-mm screw from the bottom of the
computer.
4.
Press the device latch release so that the latch release pops out.
5.
Pull the device by the latch release to remove the device from the module
bay.
|
|
|
|
|
|
|
|
|
