12V / 24V DC Power Converter with Multi Output Voltages Selection - DD90X
DD90X

Alternative Views:


Regular Price: US$99.00
Sale Price: US$59.95

Price with Selected Options: US$59.95
Condition: Brand New!
Return Allowed: 30 Days
Warranty: 1 Year

Stock Status:In Stock

Product Code: DD90X


Connector Tips*:
No Optional Connector Tips
with 8 Connector Tips [Add US$14.00]
with 12 connector tips [Add US$20.00]

Qty:
Description

This DC to DC power adapter can convert wide range input ( from 10V to 30V) power, such as 12V DC power from a car cigarette lighter socket or 24V DC power from a truck/boat cigarette lighter socket to 12/15/16/18.5/19.5/24v voltage DC output power for laptop/notebook computers, tablet computers or other devices.




It can also provide 5V USB port power for smart phones such as iPhones (USB power cable not included)




This DC power adapter can be used with vehicles with standard 12V or 24V cigarette lighters (such as cars/trucks and boats) to provide continuous power to your laptop/notebook computers and to recharge batteries. Unlike most power adapters on market, which may only accept 12V ~ 15V DC input, this DC power adapter can accept 10V ~ 30V DC power. So, it can be used for both 12V car cigarette lighter sockets and 24V truck/boat cigarette lighter sockets.



Set DC Output Voltage


This adapter has an output voltage selection switch on side. Please refer to the electronic device you are powering to determine correct voltage. It should be marked on the DC input jack. You may also refer to the manual to determine the proper voltage setting. If there is a discrepancy between the battery chart and the setting marked on your electronic devices, ALWAYS select the voltage close to it. For example, if your laptop DC input requirement is 19.5V, you can set at 19V first, then if it does not work, set at 20V.


Caution: Please set the output voltage before connecting power adapter to input & output. If you need to change the output voltage, please disconnect the power adapter from both input & output first. Do not change the output voltage when the power adapter is connected to input power source or output device. If the power adapter stops working, disconnect it from both input and output and check if there is anything wrong with the connection.



Technical Specifications:
  • Acceptable Input DC Voltage: 10V - 30V
  • Efficiency >88%(TYP)
  • Selectable Output Voltages: 5V/12V/15V/16V/18V5/19.5V/24V (±5%@ typical±0.8V)
  • Maximum output power: 90W
  • Over Load Protection (Over current & Over Voltage Protection) : Yes
  • Short Circuit Protection: Yes
  • Storage Temperature: -10℃ to 60℃
  • Operating Temperature: 0℃ to 40℃
  • Storage Humidity: 10% to 90%
  • Operating Humidity: 20% to 80%
  • Weight 0.55 lb (260g )
  • Dimension 4.5” x 2” x 1.2” (110 x 50 x 30 mm)
  • Color Black

Optional Connector Tips:

The DD90X power adapter standard package does not come with any extra connector tips. The connector on the output cable is a 5.5 x 2.5mm barrel connector with 5.5mm outside diameter and 2.5mm inside diameter:



You may order power adapter without connector tips, or with optional 12 connector tips Kit like this:


Optional Connector Tips.
